Product Introduction

This gantry packing machine is designed for bottled and canned products. The equipment consists of a gantry manipulator, an intelligent control system and a conveyor line, and the core components work together.

When the machine is working, the conveyor line transports the product to the designated station, the equipment automatically completes the size detection and automatic calibration parameters, and the manipulator accurately grabs and neatly stacks according to the preset method. The packing efficiency can reach 600 to 700 boxes per hour, which greatly improves the production capacity and significantly reduces the error rate compared to manual operation.

Product Advantages

Wide product coverage and large span

The gantry structure can span across the conveyor line and the containers to be loaded (such as pallets, cartons), and can cover a very wide working area. Suitable for handling large and heavy products. For example: large household appliances, barreled products, bagged materials, and full boxes of beverages.

High load capacity

it can easily handle overweight products that other types of case packers have difficulty handling. Equipped with a powerful servo drive system. XYZ three-axis linear motion, simple motion trajectory, easy to control, and more efficient path planning.

High-efficiency production

For large pieces, heavy objects or whole layers of products, the gantry case packer has a large span and high load capacity, which allows a large amount of products to be grabbed at a time, and the handling efficiency is very high.

Simple structure and easy maintenance

simple maintenance, high versatility of spare parts, more advantageous long-term operating costs. Simple operation, ordinary workers can operate it without any training, and time utilization is more efficient.

Product parameter

No.	MODEL	Weight capacity	Weight	Hight	SPEED	Power supply
		(KG)	(KG)	(MM)	(BOX/MIN)
1	XJ-LMZX	more than 30KG	1500KG	2000MM	10-12 BOXES/MIN	220/380V-50Hz

Application Case

Gantry packing machine enables Arawana barreled oil intelligent manufacturing upgrade: efficiency and quality leap

Background：In the field of fast-moving consumer goods manufacturing, the large-scale production of barreled edible oil faces the dual challenges of efficiency and labor costs. As a leading enterprise in China's domestic grain and oil industry, Arawana has long relied on manual packing of barreled oil. Under the traditional operation mode, workers can only complete 2 boxes of packing tasks per minute. High-intensity and repetitive physical labor not only leads to a surge in employee fatigue and lagging production efficiency, but also makes it difficult to cope with the demand for explosive orders during the peak sales season, which has become a bottleneck restricting the increase in production capacity.

Solution：Facing the growing market pressure, Arawana has finally reached a cooperation with our company after multiple rounds of technical research and equipment evaluation, and introduced an intelligent gantry packing machine. The equipment is designed based on the concept of Industry 4.0, integrating core technologies such as visual recognition, servo drive, and motion control. It can accurately locate the position of barreled oil through a three-dimensional laser scanning system, and cooperate with an adaptive gripping manipulator to automatically complete complex processes such as oil grabbing, posture adjustment, and box arrangement, realizing unmanned operation of the entire process.

After the equipment was put into production, the packing efficiency of Arawana barreled oil has achieved a qualitative leap. The gantry packer has a stable output of 10 boxes per minute, which is 5 times more efficient than manual operation, and the daily production capacity has increased by more than 400%, effectively alleviating the pressure of order delivery. The intelligent operation mode also significantly reduces the product loss caused by manual intervention. Through the flexible gripping system and anti-collision algorithm, the appearance damage rate of barreled oil has dropped by 92%, and the packaging quality has reached the industry-leading level.

In addition to improving efficiency, the application of this equipment has also promoted the transformation of production management mode. Through the docking of the MES system, the packing machine can upload operation data in real time, helping enterprises to accurately grasp the status of equipment and calculate energy consumption indicators. At the same time, 80% of the manpower input in packing positions is reduced, and the released labor force can be transferred to technical positions such as quality inspection and equipment maintenance, which promotes the optimal allocation of enterprise human resources.

Summary：This cooperation not only injects new momentum into the Arawana barreled oil production line, but also becomes a typical example of the intelligent transformation of the food manufacturing industry. In the future, our company will continue to delve deeper into the field of intelligent packaging, combine AI algorithms and digital twin technology, provide companies with more flexible and efficient automation solutions, help traditional manufacturing break through the manpower bottleneck, and achieve the dual goals of cost reduction, efficiency improvement and sustainable development.
